BS EN IEC 60072-2:2025

This standard BS EN IEC 60072-2:2025 Dimensions and output series for rotating electrical machines is classified in these ICS categories:

• 29.160.01 Rotating machinery in general

IEC 60072-2: 2025 covers the majority of rotating electrical machines for industrial purposes within the dimension range and output powers: - Foot-mounted: shaft heights: 355 mm to 1 000 mm. - Flange-mounted: pitch circle diameter of flange: 1 180 mm to 2 360 mm. It gives tables of fixing dimensions, shaft extension dimensions and their tolerances. However, the variety of construction and the wide range of applications for the large machines with shaft heights above 315 mm have led to the establishment of a relatively large number of values for the dimension in order to cover all possible constructions. Owing to this, the present part covers a wider range than IEC 60072-1 within which range values suitable for all designs or for a more detailed standardization can be chosen. NOTE The mounting dimensions given in this document for shaft heights 355 mm and 400 mm have been chosen from values given in IEC 60072-1. This second edition cancels and replaces the first edition published in 1990. This edition constitutes a technical revision. This edition includes the following significant technical changes with respect to the previous edition: a) complete revision on the basis of IEC 60072-1; b) additional tolerances and measurements for shafts and flanges (DIN SPEC 42955).
