BS EN ISO 1089:2023

This standard BS EN ISO 1089:2023 Resistance welding equipment. Electrode taper fits for spot welding equipment. Dimensions is classified in these ICS categories:

• 25.160.20 Welding consumables
• 25.160.30 Welding equipment

This document specifies the dimensions and tolerances of taper fits between the following: —     straight electrodes and electrode holders; —     electrode adapters connecting electrode caps and electrode holders; —     female electrode caps and electrode adapters; —     male electrode caps and electrode adapters. NOTE            Electrode holders and electrode caps utilizing locking tapers are addressed in ISO 20168.
