BS EN ISO 128-3:2022 Technical product documentation (TPD). General principles of representation Views, sections and cuts

BS EN ISO 128-3:2022

Technical product documentation (TPD). General principles of representation Views, sections and cuts

Format
Availability
Price and currency
Anglicky Secure PDF
Immediate download
360.59 €
Anglicky Hardcopy
In stock
360.59 €
Označení normy:BS EN ISO 128-3:2022
Počet stran:58
Vydáno:2022-09-21
ISBN:978 0 539 18580 5
Status:Standard
Počet stran (Anglicky):58
ISBN (Anglicky):978 0 539 18580 5
DESCRIPTION

BS EN ISO 128-3:2022


This standard BS EN ISO 128-3:2022 Technical product documentation (TPD). General principles of representation is classified in these ICS categories:
  • 01.100.01 Technical drawings in general
This document specifies the general principles for presenting views, sections and cuts applicable to various kinds of technical drawings (e.g. mechanical, electrical, architectural, civil engineering), following the orthographic projection methods specified in ISO 5456-2. Views and sections for shipbuilding technical drawings are discussed in ISO 128-15. Views and sections for 3D models are discussed in ISO 16792. Attention has also been given in this document to the requirements of reproduction, including microcopying in accordance with ISO 6428.
