IEC 61557-5:2019
Electrical safety in low voltage distribution systems up to 1 000 V AC and 1 500 V DC - Equipment for testing, measuring or monitoring of protective measures - Part 5: Resistance to earth
Sécurité électrique dans les réseaux de distribution basse tension au plus égale à 1 000 V c.a. et 1 500 V c.c. - Dispositifs de contrôle, de mesure ou de surveillance de mesures de protection - Partie 5: Résistance à la terre
Označení normy: | IEC 61557-5:2019 |
Vydáno: | 2019-07-26 |
Edice: | 3 |
ICS: | 17.220.20 |
Počet stran (Anglicky/Francouzsky): | 24 |
ISBN (Anglicky/Francouzsky): | 9782832271599 |
IEC 61557-5:2019
IEC 61557-5:2019 specifies the requirements applicable to measuring equipment for measuring the resistance to earth using an AC voltage. IEC 61557-5:2019 cancels and replaces the second edition published in 2007. This edition constitutes a technical revision. This edition includes the following significant technical changes with respect to the previous edition:
a) definitions and symbols in Clause 3 modified;
b) subclauses in Clause 4 restructured and aligned with other parts of the series;
c) limits for reduced voltages 25 V RMS or 35 V peak removed from 4.5;
d) requirements for clamps added;
e) marking for rated voltages to earth and measurement category added to Clause 5;
f) warning about absence of hazardous voltage added in Clause 5;
g) the term "percentage operating uncertainty" replaced by "operating uncertainty" in Clause 6;
h) equation for uncertainty corrected in Table 1;
i) new Annex A on test measurements with loop clamps added.
