Homepage>ISO 8139:2018-Pneumatic fluid power — Cylinders, 1 000 kPa (10 bar) series — Mounting dimensions of rod-end spherical eyes
sklademVydáno: 2018
ISO 8139:2018-Pneumatic fluid power — Cylinders, 1 000 kPa (10 bar) series — Mounting dimensions of rod-end spherical eyes

ISO 8139:2018

ISO 8139:2018-Pneumatic fluid power — Cylinders, 1 000 kPa (10 bar) series — Mounting dimensions of rod-end spherical eyes

Format
Availability
Price and currency
Anglicky PDF
Immediate download
48.65 €
Francouzsky PDF
Immediate download
48.65 €
Anglicky Hardcopy
In stock
48.65 €
Francouzsky Hardcopy
In stock
48.65 €
Označení normy:ISO 8139:2018
Počet stran:4
Vydání:4
Vydáno:2018
Počet stran (Anglicky):4
Počet stran (Francouzsky):4
DESCRIPTION

ISO 8139:2018


This document specifies the mounting dimensions required for interchangeability of rod-end spherical eyes of pneumatic cylinders. The rod-end spherical eyes have been designed specifically for use with 1 000 kPa [10 bar[1]] series cylinders manufactured in accordance with ISO 6432 and ISO 15552, but this does not limit their application. The spherical bearing end eyes are used on piston rods of pneumatic cylinders for mechanically transmitting the cylinder force under oscillatory rotational and tilting movements. The design of the rod-end spherical eyes is based on the maximum forces resulting from the specified internal diameter of the cylinders and pressure according to ISO 6432, ISO 15552 and ISO 21287. [1] 1 bar = 100 kPa = 105 Pa; 1 Pa = 1 N/m2.
