UNE EN 61076-2-113:2017
Connectors for electronic equipment - Product requirements - Part 2-113: Circular connectors - Detail specification for connectors with M12 screw locking with power and signal contacts for data transmission with frequency up to 100 MHz (Endorsed by Asociación Española de Normalización in July of 2017.)
Conectores para equipos electrónicos. Requisitos de producto. Parte 2-113: Conectores circulares. Especificación particular para conectores con contactos de datos y de potencia con M 12 con bloqueo con tornillo, para frecuencias hasta 100 MHz (Ratificada por la Asociación Española de Normalización en julio de 2017.)
| Označení normy: | UNE EN 61076-2-113:2017 |
| Počet stran: | 45 |
| Vydáno: | 2017-07-01 |
| Status: | Norma |
UNE EN 61076-2-113:2017
This part of IEC 61076 describes M12 circular connectors with two data pairs and power contacts with current ratings up to 12 A, that are typically used for data and power applications in industrial premises. These connectors consist of both fixed and free connectors either rewireable or non rewireable, with screw-locking. Male connectors have round contacts Ø1,50mm, Ø1,00mm and Ø0,60mm. The different codings provided by this standard prevent the mating of accordingly coded male or female connectors to any other similarly sized interfaces covered by other standards and the cross-mating between the different codings provided by this standard. Note M12 is the dimension of the thread of the screw locking mechanism of these circular connectors.
