>UNE EN IEC 63616:2026 - Measurement of the conductivity for metal thin films at microwave and millimeter-wave frequencies - Balanced-type circular disk resonator method (Endorsed by Asociación Española de Normalización in March of 2026.)
sklademVydáno: 2026-03-01
UNE EN IEC 63616:2026 - Measurement of the conductivity for metal thin films at microwave and millimeter-wave frequencies - Balanced-type circular disk resonator method (Endorsed by Asociación Española de Normalización in March of 2026.)

UNE EN IEC 63616:2026

Measurement of the conductivity for metal thin films at microwave and millimeter-wave frequencies - Balanced-type circular disk resonator method (Endorsed by Asociación Española de Normalización in March of 2026.)

Medición de la conductividad de películas metálicas delgadas en frecuencias de microondas y ondas milimétricas. Método del resonador de disco circular de tipo equilibrado (Ratificada por la Asociación Española de Normalización en marzo de 2026.)

Format
Availability
Price and currency
Anglicky PDF
Immediate download
Printable
75.60 €
Anglicky Hardcopy
In stock
75.60 €
Označení normy:UNE EN IEC 63616:2026
Počet stran:21
Vydáno:2026-03-01
Status:Norma
DESCRIPTION

UNE EN IEC 63616:2026

This document relates to a conductivity measurement method of thin metal films at microwave and millimeter-wave frequencies. This method has been developed to evaluate the conductivityof a metal foil used for adhering to a substrate or the interfacial conductivity of a metal layer formed on a dielectric substrate. It uses higher-order modes of a balanced-type circular disk resonator and provides broadband conductivity measurements by using a single resonator. In comparison with the conventional method described in IEC 61788-7, this method has the following characteristics: " the value of the conductivity 5Øß of a metal foil can be measured accurately and non-destructively; " the value of the interfacial conductivity 5Øß of a metal layer on a dielectric substrate can be measured accurately and non-destructively; " this method presents broadband measurements by using higher-order modes by one resonator; " this method is applicable for the measurements on the following condition: frequency: 10 GHz d"5ØSÜd" 170 GHz; 22 conductivity: 105 S/m d"5Øßd" 108 S/m.
