UNE EN ISO 22081:2023
Geometrical product specifications (GPS) - Geometrical tolerancing - General geometrical specifications and general size specifications (ISO 22081:2021)
Especificación geométrica de productos (GPS). Tolerancias geométricas. Especificaciones geométricas generales y especificaciones generales de dimensión. (ISO 22081:2021).
| Označení normy: | UNE EN ISO 22081:2023 |
| Počet stran: | 23 |
| Vydáno: | 2023-02-08 |
| Status: | Norma |
UNE EN ISO 22081:2023
This document gives the rules of definition and interpretation of general specifications defined according to ISO 8015 (general tolerancing) applicable on the whole workpiece. The general specifications can be applied to integral surfaces only, i.e. integral lines are excluded. The general geometrical and dimensional specifications defined in this document applies to the following: for dimensional specifications: for features of size: linear size (±) (according to ISO 14405-1); angular size (±)(according to ISO 14405-3); for geometrical specifications: for integral features: geometrical specifications with the characteristic surface profile ().
