sklademVydáno: 2021-08-04
21/30400672 DC
BS ISO 12164-2. Hollow taper interface with flange contact surface Part 2. Receivers of type A, C and E for hollow taper shanks of type A, AB, C, CB and EB
CURRENCY
| Označení normy: | 21/30400672 DC |
| Počet stran: | 14 |
| Vydáno: | 2021-08-04 |
| Status: | Draft for Comment |
DESCRIPTION
21/30400672 DC
This standard 21/30400672 DC BS ISO 12164-2. Hollow taper interface with flange contact surface is classified in these ICS categories:
- 25.060.20 Dividing and tool-workpiece holding devices
This document specifies dimensions for receivers with taper and flange contact surfaces for hollow taper shanks (HSK) in accordance with ISO 12164-1 to be applied on machine tools (e.g. for turning, drilling, milling, grinding and combinations of them).
This document specifies three types of receivers:
-
Type A for automatic tool change;
-
Type C for manual tool change only, via radial holes in both the receiver and the tool shank;
-
Type E for automatic tool change.
NOTE 1
The receivers of types A, C and E fit the HSK shanks A, AB, C, CB and EB (according to ISO 12164-1 ).
NOTE 2
HSK types A, AB and EB can also be changed manually.
