BS EN IEC 60317-62:2020

This standard BS EN IEC 60317-62:2020 Specifications for particular types of winding wires is classified in these ICS categories:

• 29.060.10 Wires

This part of IEC 60317 specifies the requirements of polyester glass-fibre wound, silicone resin or varnish impregnated bare, grade 1 or grade 2 enamelled rectangular copper winding wires, temperature index 200. The impregnating agent is a silicone containing resin or varnish.

The range of nominal conductor dimensions covered by this document is:

• width: min. 2,0 mm max. 16,0 mm;

• thickness: min. 0,80 mm max. 5,60 mm.

NOTE For this type of wire, the heat shock test is inappropriate and therefore a heat shock temperature cannot be established. Consequently, a class based on the requirements for temperature index and heat shock temperature cannot be specified.
