ISO 3019-1:2001
ISO 3019-1:2001 - Hydraulic fluid power — Dimensions and identification code for mounting flanges and shaft ends of displacement pumps and motors — Part 1: Inch series shown in metric units
Format
Availability
Price and currency
Anglicky PDF
Immediate download
Printable
79.21 €
Francouzsky PDF
Immediate download
Printable
79.21 €
Anglicky Hardcopy
In stock
79.21 €
Francouzsky Hardcopy
In stock
79.21 €
| Označení normy: | ISO 3019-1:2001 |
| Vydání: | 2 |
| Vydáno: | 2001-05-31 |
| Počet stran (Anglicky): | 12 |
| Počet stran (Francouzsky): | 12 |
DESCRIPTION
ISO 3019-1:2001
This part of ISO 3019 specifies sizes and dimensions and establishes an identification code for the two- and fourbolt
mounting flanges and the shaft ends of positive-displacement, rotary hydraulic fluid power pumps and motors.
It is applicable to cylindrical keyed shaft ends with an external thread, as well as to those without a thread, to
conical keyed shaft ends with an external thread and to 30° involute spline shaft ends.
NOTE Involute spline is in accordance with SAE J744 [1].
