ISO 5414-2:2002
ISO 5414-2:2002 - Tool chucks (end mill holders) with clamp screws for flatted cylindrical shank tools — Part 2: Connecting dimensions of chucks and designation
Format
Availability
Price and currency
Anglicky PDF
Immediate download
Printable
79.43 €
Francouzsky PDF
Immediate download
Printable
79.43 €
Anglicky Hardcopy
In stock
79.43 €
Francouzsky Hardcopy
In stock
79.43 €
| Označení normy: | ISO 5414-2:2002 |
| Vydání: | 2 |
| Vydáno: | 2002-10-25 |
| Počet stran (Anglicky): | 10 |
| Počet stran (Francouzsky): | 10 |
DESCRIPTION
ISO 5414-2:2002
ISO 5414-2 specifies the dimensions of tool chucks (end mill holders) with clamp screws for tools with flatted cylindrical shanks in accordance with ISO 3338-2. It also specifies the designations of these chucks.
ISO 5414-2 defines two types of connection:
chucks with 7/24 taper shanks in accordance with ISO 297 for manual changers and with ISO 7388-1 for automatic changers, for tool shanks with either single flat or a double flat for manual and automatic changers;
chucks with Morse taper shanks in accordance with ISO 296 and ISO 5413 for tool shanks with a single flat only.
