ISO/TS 10303-1676:2018

ISO/TS 10303-1676:2018-11 specifies the application module for Functional decomposition to design. The following are within the scope of ISO/TS 10303-1676:2018-11: the representation of the information needed to describe the assignment of a functional unit in a hierarchical network definition to an element in the physical design definition. Usually, this information is provided by a packaging application. the pin mapping between the functional view and the packaged view that is normally stored in a library and which the packaging application traverses during execution. identification of swapping of the allocation of functional unit to a physical design component with a different allocation;identification of swapping of the allocation of terminals of a functional unit to a physical design component with a different allocation.
