ISO/TS 10303-1693:2014
ISO/TS 10303-1693:2014-Industrial automation systems and integration — Product data representation and exchange — Part 1693: Application module: Layered 2D shape
CURRENCY
| Označení normy: | ISO/TS 10303-1693:2014 |
| Počet stran: | 11 |
| Vydání: | 3 |
| Vydáno: | 2014 |
| Jazyk: | Anglicky |
DESCRIPTION
ISO/TS 10303-1693:2014
ISO/TS 10303-1693:2014-02 specifies the application module for Layered 2D shape. The following are within the scope of ISO/TS 10303-1693:2014-02: identification of a geometric model, that defines shape lying on a two-dimensional plane; identification of a geometric model, that defines real features in product model projected on a two-dimensional plane; items within the scope of application module Constructive solid geometry 2d, ISO/TS 10303-1731; items within the scope of application module Shape feature, ISO/TS 10303-1764; items within the scope of application module Wireframe 2d, ISO/TS 10303-1347.
