ISO/TS 10303-1792

ISO/TS 10303-1792:2018-11 specifies the application module for Sketch. The following are within the scope of ISO/TS 10303-1792:2018-11: sketches as planar geometric constructs for use in the generation of surfaces and solids by means of sweep operations and other operations of related types; neutral two dimensional sketches, defined in general coordinate systems; positioned sketches, defined in three-dimensional model space; relationships between neutral two dimensional sketches and positioned sketches defined by mappings; the use of parameters and constraints to define variational sketches; NOTE    the ability to constrain geometric elements of sketches is available when this module is used with the geometric constraints module. subsketches as partial sketches subject to special treatment; geometric elements imported into the plane of a sketch but defined in terms of other model elements lying outside that plane, used for constraining sketch elements with respect to external geometry; items within the scope of application module Geometric constraints, ISO/TS 10303-1789.
