UNE EN 16727-2-2:2016
Railway applications - Track - Noise barriers and related devices acting on airborne sound propagation - Non-acoustic performance - Part 2-2: Mechanical performance under dynamic loadings caused by passing trains - Calculation method
Aplicaciones ferroviarias. Vía. Barreras acústicas y dispositivos relacionados que actúan sobre la propagación aérea del sonido. Rendimiento no acústico. Parte 2-2: Prestaciones mecánicas bajo cargas dinámicas producidas por el paso de trenes. Método de cálculo.
| Označení normy: | UNE EN 16727-2-2:2016 |
| Počet stran: | 25 |
| Vydáno: | 2016-11-16 |
| Status: | Norma |
| Počet stran (Španělsky): | 26 |
UNE EN 16727-2-2:2016
This European standard defines the loading, the relevant load model positions and the internal forces of noise barriers caused by the air pressure wave of passing trains based on EN 1991 2, Eurocode 1, subclause 6.6.2. The vertical and horizontal shape of the air pressure wave and the dynamic effects has been taken into account. The calculation method described in this European standard has been developed for noise barriers having a post-panel structure with pile foundations and can also be used for claddings attached to rigid structures. For pile-founded structures an empirical formula for the determination of the natural frequency is given in Annex A, and in Annex B an example of use is shown.
