UNE EN IEC 61788-15:2026
Superconductivity - Part 15: Electronic characteristic measurements - Intrinsic surface impedance of superconductor films at microwave frequencies (Endorsed by Asociación Española de Normalización in June of 2026.)
Superconductividad. Parte 15: Medida de las características electrónicas. Impedancia de la superficie intrínseca de películas superconductoras a las frecuencias de microondas. (Ratificada por la Asociación Española de Normalización en junio de 2026.)
| Označení normy: | UNE EN IEC 61788-15:2026 |
| Vydáno: | 2026-06-01 |
| Status: | Norma |
| Počet stran (Anglicky): | 65 |
UNE EN IEC 61788-15:2026
This part of IEC 61788 describes measurements of the intrinsic surface impedance (ZS) of HTS films at microwave frequencies by a modified two-resonance mode dielectric resonator method [14, 15]. The object of measurement is to obtain the temperature dependence of the intrinsic surface impedance, ZS, at the resonant frequency f0. The frequency and thickness range and the measurement resolution for the ZS of HTS films are as follows: " frequency: Up to 40 GHz; " film thickness: Greater than 50 nm; " measurement resolution: 0,01 m© at 10 GHz. The ZS data at the measured frequency, and that scaled to 10 GHz, assuming the f2 rule for the intrinsic surface resistance, RS (f < 40 GHz), and the f rule for the intrinsic surface reactance, XS, for comparison, shall be reported.
