UNE EN IEC 62153-4-16:2022
Metallic cables and other passive components test methods - Part 4-16: Electromagnetic compatibility (EMC) - Extension of the frequency range to higher frequencies for transfer impedance and to lower frequencies for screening attenuation measurements using the triaxial set-up
Métodos de ensayo de cables metálicos y otros componentes pasivos. Parte 4-16: Compatibilidad electromagnética (CEM). Extensión del rango de frecuencias a frecuencias superiores para la impedancia de transferencia y a frecuencias inferiores para la medición de la atenuación de apantallamiento con el uso de un montaje triaxial.
| Označení normy: | UNE EN IEC 62153-4-16:2022 |
| Počet stran: | 28 |
| Vydáno: | 2022-04-06 |
| Status: | Norma |
| Počet stran (Španělsky): | 30 |
UNE EN IEC 62153-4-16:2022
This part of IEC 62153 describes a method to extrapolate the test results of transfer impedance to higher frequencies and the test results of screening attenuation to lower frequencies when measured with the triaxial set-up according to IEC 62153-4-3, IEC 62153-4-4 respectively IEC 62153-4-15. This method is applicable for homogenous screens, i.e. screens having a transfer impedance directly proportional to length. The transfer impedance may have any frequency behaviour, i.e. it could have a behaviour where it does not increase with 20 dB per decade as observed for screens made of a foil and a braid.
