BS EN IEC 63093-10:2022

This standard BS EN IEC 63093-10:2022 Ferrite cores. Guidelines on dimensions and the limits of surface irregularities is classified in these ICS categories:

• 29.100.10 Magnetic components

IEC 63093-10:2022 specifies the dimensions that are of importance for mechanical interchangeability for a preferred range of PM-cores made of magnetic oxides, the main dimensions for coil formers to be used with these cores and the locations of their pins on a modular printed wiring grid in relation to the base outlines of cores. It also specifies the effective parameter values to be used in calculations and gives guidelines on allowable limits of surface irregularities applicable to the PM-cores.
