Hlavní stránka>BS EN ISO 13715:2019 Technical product documentation. Edges of undefined shape. Indication and dimensioning
sklademVydáno: 2019-10-29
BS EN ISO 13715:2019 Technical product documentation. Edges of undefined shape. Indication and dimensioning

BS EN ISO 13715:2019

Technical product documentation. Edges of undefined shape. Indication and dimensioning

Formát
Dostupnost
Cena a měna
Anglicky Zabezpečené PDF
K okamžitému stažení
6380 Kč
Anglicky Tisk
Skladem
6380 Kč
Označení normy:BS EN ISO 13715:2019
Počet stran:30
Vydáno:2019-10-29
ISBN:978 0 539 03499 8
Status:Standard
Počet stran (Anglicky):30
ISBN (Anglicky):978 0 539 03499 8
Popis

BS EN ISO 13715:2019


This standard BS EN ISO 13715:2019 Technical product documentation. Edges of undefined shape. Indication and dimensioning is classified in these ICS categories:
  • 01.100.20 Mechanical engineering drawings
  • 01.040.01 Generalities. Terminology. Standardization. Documentation (Vocabularies)
ISO 13715:2017 specifies rules for the indication and dimensioning of undefined edges in technical product and dimensions. The proportions and dimensions of the graphical symbols to be used are also specified. In cases where the geometrically defined shape of an edge (for example, 1 × 45°) is required, the general dimensioning principles given in ISO 129? 1 apply.
