IEC 60512-26-100:2008
Connectors for electronic equipment - Tests and measurements - Part 26-100: Measurement setup, test and reference arrangements and measurements for connectors according to IEC 60603-7 - Tests 26a to 26g
Connecteurs pour équipements électroniques - Essais et mesures - Partie 26-100: Montage de mesure, dispositifs d'essai et de référence et mesures pour les connecteurs conformes à la CEI 60603-7 - Essais 26a à 26g
| Označení normy: | IEC 60512-26-100:2008 |
| Vydáno: | 2008-07-21 |
| Edice: | 1 |
| ICS: | 31.220.10 |
IEC 60512-26-100:2008
IEC 60512-26-100:2008 specifies the test and measurements and the related measurement setup and reference arrangements for interoperability and backward compatibility tests for the development and qualification of 8-way, free and fixed connectors for data transmission. The following test methods are provided:
- insertion loss, test 26a;
- return loss, test 26b;
- near-end crosstalk (NEXT), test 26c;
- far-end crosstalk (FEXT), test 26d;
- transfer impedance, test 26e;
- transverse conversion loss (TCL), test 26f;
- transverse conversion transfer loss (TCTL), test 26g.
This publication is to be read in conjunction with IEC 60512-1:2001 and IEC 60512-1-100:2006.
