IEC 61169-17:2022
Radio-frequency connectors - Part 17: Sectional specification for RF coaxial connectors with inner diameter of outer conductor 6,5 mm (0,256 in) with screw coupling - Characteristic impedance 50 ohms (Type TNC)
Connecteurs pour fréquences radioélectriques - Partie 17: Spécification intermédiaire relative aux connecteurs RF coaxiaux à couplage à vis avec conducteur extérieur présentant un diamètre intérieur de 6,5 mm (0,256 in) - Impédance caractéristique de 50 ohms (type TNC)
| Označení normy: | IEC 61169-17:2022 |
| Vydáno: | 2022-03-04 |
| Edice: | 1 |
| ICS: | 33.120.30 |
| Počet stran (Anglicky/Francouzsky): | 50 |
| ISBN (Anglicky/Francouzsky): | 9782832248164 |
IEC 61169-17:2022
IEC 61169-17:2022, which is a sectional specification (SS), provides information and rules for the preparation of detail specifications (DS) for series TNC RF coaxial connectors with threaded coupling with a characteristic impedance of 50 Ω.
This document prescribes mating face dimensions for high performance connectors - grade 2, dimensional details of standard test connectors - grade 0, gauging information and tests selected from IEC 61169-1, applicable to all detail specifications relating to series TNC RF connectors.
This document indicates recommended performance characteristics to be considered when writing a detail specification and it covers test schedules and inspection requirements for assessment levels M and H.
