IEC 61188-7:2017
Printed boards and printed board assemblies - Design and use - Part 7: Electronic component zero orientation for CAD library construction
Cartes imprimées et cartes imprimées équipées - Conception et utilisation - Partie 7: Orientation nulle des composants électroniques pour l'élaboration d’une bibliothèque CAO
Formát
Dostupnost
Cena a měna
Anglicky/Francouzsky PDF
K okamžitému stažení
3289 Kč
Anglicky Tisk
skladem
3289 Kč
Anglicky PDF
K okamžitému stažení
3289 Kč
| Označení normy: | IEC 61188-7:2017 |
| Vydáno: | 2017-04-10 |
| Edice: | 2 |
| ICS: | 31.180 |
Popis
IEC 61188-7:2017
IEC 61188-7:2017 establishes a consistent technique for the description of electronic component orientation, and their land pattern geometries. This facilitates and encourages a common data capture and transfer methodology amongst and between global trading partners.
This edition includes the following significant technical changes with respect to the previous edition:
a) Figure 1 has been corrected;
b) the term “rectangle” has generally been replaced by “polygon”;
c) level B has been indicated as preferred level for new libraries.
