IEC 61240:2016
Piezoelectric devices - Preparation of outline drawings of surface-mounted devices (SMD) for frequency control and selection - General rules
Dispositifs piezoélectriques - Préparation des dessins d'encombrement des dispositifs pour montage en surface pour la commande et le choix de la fréquence - Règles générales
| Označení normy: | IEC 61240:2016 |
| Vydáno: | 2016-10-24 |
| Edice: | 3 |
| ICS: | 31.140 |
| Počet stran (Anglicky): | 18 |
| ISBN (Anglicky): | 9782832236925 |
| Počet stran (Anglicky/Francouzsky): | 36 |
| ISBN (Anglicky/Francouzsky): | 9782832251591 |
IEC 61240:2016
IEC 61240:2016 sets out general rules for drawing all dimensional and geometrical characteristics of a surface-mounted piezoelectric device package (referred to in this document as SMD) in order to ensure mechanical inter-changeability of all outline drawings of the SMDs for frequency control and selection. This edition includes the following significant technical changes with respect to the previous edition:
- outline drawings have been changed from three views (top, front and bottom) to that based on ISO layout in the third-angle projection, in which the view from the right has been added to the top, front and bottom views;
- reference line and geometrical dimensions of the package for enclosures have been changed for practical use;
- information on miniaturized leadless ceramic enclosures of piezoelectric devices (SMD) for frequency control and selection has been included in an annex.
