IEC 61850-7-1:2011
Communication networks and systems for power utility automation - Part 7-1: Basic communication structure - Principles and models
Réseaux et systèmes de communication pour l'automatisation des systèmes électriques - Partie 7-1: Structure de communication de base - Principes et modèles
| Označení normy: | IEC 61850-7-1:2011 |
| Vydáno: | 2011-07-15 |
| Edice: | 2 |
| ICS: | 33.200 |
IEC 61850-7-1:2011
IEC 61850-7-1:2011 introduces the modelling methods, communication principles, and information models that are used in the various parts of the IEC 61850-7 series. The purpose is to provide - from a conceptual point of view - assistance to understand the basic modelling concepts and description methods for:
- substation-specific information models for power utility automation systems,
- device functions used for power utility automation purposes, and
- communication systems to provide interoperability within power utility facilities. Compared to the first edition, this second edition introduces:
- the model for statistical and historical statistical data,
- the concepts of proxies, gateways, LD hierarchy and LN inputs,
- the model for time synchronisation,
- the concepts behind different testing facilities,
- the extended logging function. It also clarifies certain items.
