IEC 62196-2:2022
Plugs, socket-outlets, vehicle connectors and vehicle inlets - Conductive charging of electric vehicles - Part 2: Dimensional compatibility requirements for AC pin and contact-tube accessories
Fiches, socles de prise de courant, prises mobiles de véhicule et socles de connecteurs de véhicules - Charge conductive des véhicules électriques - Partie 2: Exigences dimensionnelles de compatibilité pour les appareils à broches et alvéoles pour courant alternatif
| Označení normy: | IEC 62196-2:2022 |
| Vydáno: | 2022-10-19 |
| Edice: | 3 |
| ICS: | 29.120.30 |
| Počet stran (Anglicky/Francouzsky): | 134 |
| ISBN (Anglicky/Francouzsky): | 9782832259313 |
IEC 62196-2:2022
IEC 62196-2:2022 applies to EV plugs, EV socket-outlets, vehicle connectors and vehicle inlets with pins and contact-tubes of standardized configurations, herein referred to as accessories. These accessories have a nominal rated operating voltage not exceeding 480 V AC, 50 Hz to 60 Hz, and a rated current not exceeding 63 A three phase or 70 A single phase, for use in conductive charging of electric vehicles.
This document covers the basic interface accessories for vehicle supply as specified in IEC 62196-1.
This third edition cancels and replaces the second edition published in 2016. This edition constitutes a technical revision.
This edition includes the following significant technical changes with respect to the previous edition:
interchangeability requirements have been removed from the title of Part 2;
alignment with IEC 62196-1:2022 and IEC 62196-3:2022;
alignment with IEC 61851-1:2017.
