20/30408276 DC

This standard 20/30408276 DC BS EN ISO 24200. Petroleum, petrochemical and natural gas industries. Bulk material for offshore projects. Pipe support is classified in these ICS categories:

• 75.180.10 Exploratory, drilling and extraction equipment

This document specifies the requirements for design including shape and dimensions, material as well as strength for pipe support from NPS 2 up to NPS 36 except for U-bolt and U-strap. This document covers topside systems for fixed or floating offshore oil and gas projects. This document applies for design temperature of support within the range between –23 °C up to 200 °C. This document is limited to metallic pipes only.

This document covers such requirements for following pipe supports:

• clamped shoe;

• welded shoe;

• U-bolt;

• U-strap;

• bracing for branch connection;

• trunnion and stanchion;

• guide support(guide, hold-down, guide/hold-down).

This document addresses design requirements of the listed items above, hence the document does not necessarily cover all other types of pipe supports.
