Hlavní stránka>21/30398239 DC BS ISO 12164-6. Hollow taper interface with flange contact surface Part 6. Receivers of type AS, CS and ES for hollow taper shanks of type AS, CS and ES
Not available online - contact us!
sklademVydáno: 2021-08-04
21/30398239 DC BS ISO 12164-6. Hollow taper interface with flange contact surface Part 6. Receivers of type AS, CS and ES for hollow taper shanks of type AS, CS and ES

21/30398239 DC

BS ISO 12164-6. Hollow taper interface with flange contact surface Part 6. Receivers of type AS, CS and ES for hollow taper shanks of type AS, CS and ES

Měna
560 Kč
Označení normy:21/30398239 DC
Počet stran:13
Vydáno:2021-08-04
Status:Draft for Comment
Popis

21/30398239 DC


This standard 21/30398239 DC BS ISO 12164-6. Hollow taper interface with flange contact surface is classified in these ICS categories:
  • 25.060.20 Dividing and tool-workpiece holding devices

This document specifies dimensions for receivers with taper and flange contact surfaces for hollow taper shanks (HSK) in accordance with ISO 12164-5 to be applied to machine tools (e.g. machines for turning, drilling, milling and grinding).

This document specifies three types of receivers:

  • Type AS for automatic tool change;

  • Type CS for manual tool change only, via radial holes in both the receiver and the tool shank;

  • Type ES for automatic tool change.

NOTE 1

The receivers of types AS, CS and ES fit the HSK shanks AS, CS and ES (according to ISO 12164-5 ).

NOTE 2

HSK types AS and ES can also be changed manually.
