BS EN IEC 63093-11:2018

This standard BS EN IEC 63093-11:2018 Ferrite cores. Guidelines on dimensions and the limits of surface irregularities is classified in these ICS categories:

• 29.100.10 Magnetic components

This part of IEC 63093 specifies the dimensions that are of importance for mechanical interchangeability for a preferred range of EC-cores made of ferrite and the essential dimensions of coil formers to be used with them, as well the effective parameter values to be used in calculations involving them. It also gives guidelines on allowable limits of surface irregularities applicable to EC-cores.

The specifications contained in this document are useful in negotiations between ferrite core manufacturers and customers about surface irregularities.
