BS EN ISO 6149-4:2017
Connections for fluid power and general use. Ports and stud ends with ISO 261 metric threads and O-ring sealing Dimensions, design, test methods and requirements for external hex and internal hex port plugs
| Označení normy: | BS EN ISO 6149-4:2017 |
| Počet stran: | 18 |
| Vydáno: | 2017-10-05 |
| ISBN: | 978 0 580 94276 1 |
| Status: | Standard |
BS EN ISO 6149-4:2017
This standard BS EN ISO 6149-4:2017 Connections for fluid power and general use. Ports and stud ends with ISO 261 metric threads and O-ring sealing is classified in these ICS categories:
- 23.100.40 Piping and couplings
This document specifies dimensions and performance requirements for external hex and internal hex port plugs for use with ISO 6149‑1 ports.
Port plugs in accordance with this document can be used at working pressures up to 63 MPa (630 bar1). The permissible working pressure depends upon the plug end size, materials, design, working conditions, application, etc.
Conformance to the dimensional information in this document does not guarantee rated performance. Each manufacturer is expected to perform testing according to the specification contained in this document to assure that components comply with the performance ratings.
WARNING The use of stud ends conforming to this document with ports conforming to the relevant parts of ISO 1179 , ISO 9974 and ISO 11926 could lead to a hazardous situation.
1 1 bar = 0,1 MPa = 105 Pa; 1 MPa = 1 N/mm2.
