BS ISO 6358-3:2014

This standard BS ISO 6358-3:2014 Pneumatic fluid power. Determination of flow-rate characteristics of components using compressible fluids is classified in these ICS categories:

• 23.100.01 Fluid power systems in general

This part of ISO 6358 specifies a method that uses a simple numerical technique to estimate without measurements the overall flow-rate characteristics of a system of components and piping with known flow-rate characteristics.

The formulae used in this part of ISO 6358 describe the behaviour of a compressible fluid flow through a component for both subsonic and choked flows.

NOTE The conductance of a tube, silencer or filter is influenced by the upstream pressure, so the values of C and b are only valid for the upstream pressure at which they are determined.

This part of ISO 6358 also provides methods to obtain equivalent flow-rate characteristics for components whose flow-rate characteristics differ from those defined in the ISO 6358 series.
