Cena s DPH / bez DPH
Published date: 20.11.2012
IPC-2221 - Revision B
Generic Standard on Printed Board Design
Formát
Dostupnost
Cena a měna
English Zabezpečené PDF
K okamžitému stažení
Netisknutelné
4861 Kč
English Tisk
10-14 dní
7291 Kč
French Zabezpečené PDF
K okamžitému stažení
Netisknutelné
6863 Kč
French Tisk
10-14 dní
10295 Kč
German Zabezpečené PDF
K okamžitému stažení
Netisknutelné
6863 Kč
German Tisk
10-14 dní
10295 Kč
Japanese Zabezpečené PDF
K okamžitému stažení
Netisknutelné
6863 Kč
Japanese Tisk
10-14 dní
10295 Kč
View table of Contents
| Standard Number: | IPC-2221 - Revision B |
| Published date: | 20.11.2012 |
| DOD Adopted: | No |
| ANSI Approved: | No |
| Revision: | B |
| ISBN (English): | 978-1-61193-069-6 |
| Pages (English): | 170 |
| ISBN (German): | 978-1-61193-115-0 |
| Pages (German): | 170 |
| ISBN (French): | 978-1-61193-115-0 |
| Pages (French): | 170 |
| ISBN (Japanese): | 978-1-61193-490-8 |
| Pages (Japanese): | 184 |
Popis
Superseded by IPC-2221-Revision C
IPC-2221B is the foundation design standard for all documents in the IPC-2220 series. It establishes the generic requirements for the design of printed boards and other forms of component mounting or interconnecting structures, whether single-sided, double-sided or multilayer. Among the many updates to Revision B are new criteria for conductor characteristics, surface finishes, via protection, board electrical test, dielectric properties, board housings, thermal stress, compliant pins, panelization and internal and external foil thicknesses. Appendix A provides new test coupon designs used for lot acceptance and quality conformance testing. 170 pages. Released 2012.
