IPC-2222 - Revision B
Sectional Design Standard for Rigid Organic Printed Boards
Formát
Dostupnost
Cena a měna
Chinese Zabezpečené PDF
K okamžitému stažení
Netisknutelné
3317 Kč
Chinese Tisk
10-14 dní
4975 Kč
English Zabezpečené PDF
K okamžitému stažení
Netisknutelné
3317 Kč
English Tisk
10-14 dní
4975 Kč
French Zabezpečené PDF
K okamžitému stažení
Netisknutelné
5612 Kč
French Tisk
10-14 dní
8417 Kč
View table of Contents
| Standard Number: | IPC-2222 - Revision B |
| Published date: | 01.10.2020 |
| DOD Adopted: | No |
| ANSI Approved: | No |
| Revision: | B |
| ISBN (English): | 978-1-951577-71-1 |
| Pages (English): | 36 |
| ISBN (Chinese): | 978-1-63816-049-6 |
| Pages (Chinese): | 36 |
| ISBN (French): | 978-1-951577-96-4 |
| Pages (French): | 36 |
Popis
IPC-2222B used in conjunction with IPC-2221, establishes the specific requirements for the design of rigid organic printed boards and other forms of component mounting and interconnecting structures. The IPC-2222B standard applies to single-sided, double-sided, or multi-layered boards. Key concepts in IPC-2222B are rigid laminate properties, design requirements for printed board assembly and design requirements for holes/interconnections. Revision B provides new design guidance and requirements for laminate selection, scoring and routing parameters, printed board thickness tolerance, nonfunctional lands, hole aspect ratios, via hole size and printed board edge spacing.
