IPC-2223 - Revision E
Sectional Design Standard for Flexible/Rigid-Flexible Printed Boards
Formát
Dostupnost
Cena a měna
Chinese Zabezpečené PDF
K okamžitému stažení
Netisknutelné
4130 Kč
Chinese Tisk
10-14 dní
6196 Kč
English Zabezpečené PDF
K okamžitému stažení
Netisknutelné
4130 Kč
English Tisk
10-14 dní
6196 Kč
View table of Contents
| Standard Number: | IPC-2223 - Revision E |
| Published date: | 01.01.2020 |
| DOD Adopted: | No |
| ANSI Approved: | No |
| Revision: | E |
| ISBN (English): | 978-1-951577-00-1 |
| Pages (English): | 60 |
| ISBN (Chinese): | 978-1-951577-24-7 |
| Pages (Chinese): | 60 |
Popis
IPC-2223E used in conjunction with IPC-2221, IPC-2223 establishes the specific requirements for the design of flexible printed boards and forms of component mounting and interconnecting structures. The flexible materials used in the structures are comprised of insulating films, reinforced and/or non-reinforced dielectric in combination with metallic materials. IPC-2223E provides new design guidance and requirements for fabrication drawings, hole to edge spacing, bend area conductor considerations, dielectric thickness between rigid and flexible regions and dual row zero insertion force (ZIF) connectors.
