ISO/TS 10303-1230:2005

ISO/TS 10303-1230:2005 specifies the application module for Configuration controlled 3d parts and assemblies. The following are within the scope of ISO/TS 10303-1230:2005: products that are three-dimensional parts and assemblies; configuration control data and product definition data; shape representations that includes advanced boundary representation, faceted boundary representation, manifold manifold surfaces with topology, geometrically bounded surface and wireframe geometry, wireframe with topology, and constructive solid geometry in three-dimensions; geometric presentation of geometric shape representations by the application of colours, layers and groups; geometric and dimensional tolerances applied to geometric shape representations; textual annotation and notes applied to geometric shape representations.
