>UNE CLC/TS 50238-2:2020 - Railway applications - Compatibility between rolling stock and train detection systems - Part 2: Compatibility with track circuits (Endorsed by Asociación Española de Normalización in August of 2020.)
sklademVydáno: 2020-08-01
UNE CLC/TS 50238-2:2020 - Railway applications - Compatibility between rolling stock and train detection systems - Part 2: Compatibility with track circuits (Endorsed by Asociación Española de Normalización in August of 2020.)

UNE CLC/TS 50238-2:2020

Railway applications - Compatibility between rolling stock and train detection systems - Part 2: Compatibility with track circuits (Endorsed by Asociación Española de Normalización in August of 2020.)

Aplicaciones ferroviarias. Compatibilidad entre el material rodante y los sistemas de detección de trenes. Parte 2: Compatibilidad con los circuitos de vía (Ratificada por la Asociación Española de Normalización en agosto de 2020.)

Formát
Dostupnost
Cena a měna
Anglicky PDF
K okamžitému stažení
Tisknutelné
2682 Kč
Anglicky Tisk
Skladem
2682 Kč
Označení normy:UNE CLC/TS 50238-2:2020
Počet stran:45
Vydáno:2020-08-01
Status:Norma
Popis

UNE CLC/TS 50238-2:2020

This document defines, for the purpose of ensuring compatibility between rolling stock and track circuits, the limits for interference current emissions from rolling stock. The measurement and evaluation methods for verifying conformity of rolling stock to these limits are presented in a dedicated annex. The interference limits are only applicable to rolling stock that is intended to run on lines exclusively equipped with preferred track circuits listed in this document. The rolling stock test methodology (infrastructure conditions, test configurations, operational conditions, etc.) presented in this document is applicable to establish compatibility with any track circuits. This document gives guidance on the derivation of interference current limits specified for rolling stock and defines measurement methods and evaluation criteria in a dedicated annex. This document defines: a) a set of interference current limits for RST (Rolling Stock) applicable for each of the following types of traction system: 1) DC (750 V, 1,5 kV and 3 kV); 2) 16,7 Hz AC; 3) 50 Hz AC; b) methodology for the demonstration of compatibility between rolling stock and track circuits; c) measurement method to verify interference current limits and evaluation criteria. NOTE 1 The basic parameters of track circuits associated with the interference current limits for RST are not in the scope of this document. NOTE 2 Any phenomena linked to traction power supply and associated protection (over voltage, short-circuit current, under- and over-voltage if regenerative brakes are used) is part of the track circuit design and outside the scope of this document.

:
