UNE EN 60603-7-82:2016
Connectors for electronic equipment - Part 7-82: Detail specification for 8-way, 12 contacts, shielded, free and fixed connectors, for data transmission with frequencies up to 2 000 MHz (Endorsed by Asociación Española de Normalización in February of 2017.)
Conectores para equipos electrónicos. Parte 7-82: Especificación particular para conectores de 8 vías y 12 contactos, blindados, libres y fijos, para la transmisión de datos con frecuencias de hasta 2 000 MHz (Ratificada por la Asociación Española de Normalización en febrero de 2017.)
| Označení normy: | UNE EN 60603-7-82:2016 |
| Počet stran: | 27 |
| Vydáno: | 2017-02-01 |
| Status: | Norma |
UNE EN 60603-7-82:2016
This part of IEC 60603 covers 8-way, 12 contacts, shielded, free and fixed connectors, references dimensional, mechanical, electrical and environmental characteristics and tests in IEC 60603-7-7, and specifies electrical transmission requirements, including power sum alien (exogenous) crosstalk , for frequencies up to 2 000 MHz. These connectors are typically used as category 8.2 connectors in class II cabling systems specified in ISO/IEC TR 11801-9901and specified in ISO/IEC 11801-1. These connectors are intermateable and interoperable with other IEC 60603-7 series connectors, i.e. as defined in IEC 60603-7-7 and IEC 60603-7-1. These connectors are backward compatible with other IEC 60603-7 series connectors. NOTE Transmission performance categories: in this IEC standard, the term category , when used in reference to transmission performance, refers to those categories defined by ISO/IEC 11801.
