UNE EN IEC 61169-65:2021
Radio-frequency connectors - Part 65: Sectional specification for RF coaxial connectors, 1,35 mm inner diameter of outer conductor, with screw-coupling, characteristic impedance 50 O
Conectores para radiofrecuencia. Parte 65: Especificación intermedia de conectores coaxiales para frecuencias radioeléctricas (RF), diámetro interior del conductor exterior de 1,35 mm, con acoplamiento por tornillo, impedancia característica 50 ohmios.
| Označení normy: | UNE EN IEC 61169-65:2021 |
| Počet stran: | 30 |
| Vydáno: | 2021-06-30 |
| Status: | Norma |
| Počet stran (Španělsky): | 31 |
UNE EN IEC 61169-65:2021
This part of IEC 61169, which is a sectional specification (SS), provides information and rules for the preparation of detail specifications (DS) for series1,35mmRF coaxial connectors withscrew coupling, characteristic impedance 50 ©, foroperating frequenciesup to 90GHz. Typical use in test and measurement applications. It describes mating face dimensions for general purpose connectors - grade 1, dimensional details of standard test connectors-grade 0, gauging information and tests selected from IEC 61169-1, applicable to all detail specifications relating to series1,35mmRF connectors. This specification indicates recommended performance characteristics to be considered when writing a detail specification and it covers test schedules and inspection requirements for assessment levels M and H. Note: Metric dimension are original dimensions. All undimensioned pictorial configurations are for reference purpose only.
