UNE EN IEC 62496-2-5:2023
Optical circuit boards - Basic test and measurement procedures - Part 2-5: Flexibility test for flexible opto-electric circuits (Endorsed by Asociación Española de Normalización in March of 2023.)
Placas de circuitos ópticos. Ensayos básicos y procedimientos de medición. Parte 2-5: Ensayo de flexibilidad para los circuitos ópticos-eléctricos (Ratificada por la Asociación Española de Normalización en marzo de 2023.)
| Označení normy: | UNE EN IEC 62496-2-5:2023 |
| Počet stran: | 29 |
| Vydáno: | 2023-03-01 |
| Status: | Norma |
UNE EN IEC 62496-2-5:2023
This part of IEC 62496-2 defines a test method for folding flexibility inspection of flexible opto electric circuits with a MIT folding endurance tester and presents a guideline for a step stress test method for finding the predetermined minimum mechanical folding radii below which the flexible opto-electric circuits can be damaged by intended folding distortion. Here, test samples are used instead of products for the flexibility test of their flexible opto-electric circuits, and the test samples have the same layer structure as the products.
