Cena s DPH / bez DPH
Published date: 01.05.2003
IPC-2221 - Revision A
Generic Standard on Printed Board Design
Formát
Dostupnost
Cena a měna
Chinese Zabezpečené PDF
K okamžitému stažení
Netisknutelné
4861 Kč
Chinese Tisk
10-14 dní
7291 Kč
English Zabezpečené PDF
K okamžitému stažení
Netisknutelné
4861 Kč
English Tisk
10-14 dní
7291 Kč
German Zabezpečené PDF
K okamžitému stažení
Netisknutelné
6863 Kč
German Tisk
10-14 dní
10295 Kč
View table of Contents
| Standard Number: | IPC-2221 - Revision A |
| Published date: | 01.05.2003 |
| DOD Adopted: | No |
| ANSI Approved: | No |
| Revision: | A |
| Pages (English): | 124 |
| Pages (Chinese): | 128 |
| Pages (German): | 112 |
Popis
Superseded by IPC-2221-Revision B
IPC-2221A is the foundation design standard for all documents in the IPC-2220 series. It establishes the generic requirements for the design of printed boards and other forms of component mounting or interconnecting structures, whether single-sided, double-sided or multilayer. Among the many updates to Revision A are new criteria for surface plating, internal and external foil thicknesses, component placement and hole tolerances. Expanded coverage is provided for material properties, dimensioning and tolerancing rules, and via structures as well as updated coupon designs for quality assurance. 112 pages. Released May 2003.
